Heavy Duty Tow Strap 180,000 lb Break Strength for Tippers, Wheel Loaders, and Cat D6 / D7 Dozers
- Minimum Breaking Strength: 100,000 lbs
- Working Load Limit (WLL 3.1): 60,000 lbs
- Working Load Limit (WLL 5.1): 36,000 lbs
- Class 7 Polyester Webbing
- Multi-use: Towing, Recovery, Winch Extension
Couldn't load pickup availability
|
From 2 units
−5%
From 10 units
−8%
From 20 units
P.O.A
|
Volume Discount Available
Request a Quote
|
Product and User Safety Information
Suitable Vehicle Types
- 400–600 HP Tractors
- Large Combines
- Semis / Tippers
- Wheel Loaders
- Cat D6 / D6 XE / D7 Dozers
For vehicles with a drawbar pull / GVW of upto 60,000 lbs
Product Description
180,000 lb MBS Tow / Recovery Strap
High-tonnage recovery requires a system that can handle extreme loads while maintaining control.
This 180,000 lb tow strap is matched to equipment such as dump trucks, excavators, and wheel loaders. These machines typically operate within drawbar pull ranges of 35,000 to 60,000 lb, making this strap suitable for controlled heavy recovery.
In applications involving loaded vehicles, maintaining stability is critical. Controlled traction avoids sudden force that could shift loads or introduce additional hazards.
The polyester construction allows operators to apply steady force, ensuring a predictable recovery process even in challenging terrain.
Key Features
- Built for dump trucks, excavators, and heavy construction machinery
- 60,000 lb working load limit for high-resistance recoveries
- Low-stretch polyester supports stable, high-force traction
- Designed for winching and steady pulling only
- Safer and more practical to handle than steel recovery gear
Technical Specifications
Shipping & Returns
- We cover standard shipping on all orders.
- Expedited shipping options are available at checkout for an additional fee.
- Orders are processed and shipped within 3–5 business days.
- 30-day returns available on eligible items, subject to standard return conditions
180,000 lbs | HEAVY RECOVERY STANDARD
Static Recovery for Agriculture & Construction
Professional Recovery Standard
180,000 lb sits in the professional recovery category for heavy agricultural and mid range construction machinery. Designed for controlled field recovery using standard recovery vehicles.
High-Load Field Performance
Suitable for high-resistance recovery situations involving heavy plant, agricultural machinery, and construction equipment operating under load.
Controlled Static Recovery
Designed for steady, low-stretch force transfer. Enables predictable recovery behaviour under load without shock loading or dynamic rebound.
Heavy Recovery Boundary Zone
This strap represents the upper range of single-vehicle recovery capability in most field operations. It is commonly used where heavy machinery is immobilised under load or where ground resistance prevents controlled movement.
In borderline conditions such as steep gradients, fully loaded haul units, or extreme resistance, recovery capability should be reassessed to ensure system capacity matches total drawbar pull requirements.
THE PROCESS
How Static Recovery Works
Static tow straps are designed for controlled, low-stretch recovery. Force is applied steadily and directly to move the vehicle without sudden loading or snap-back. At this level, recovery execution must account for total load resistance and operating conditions.
Position & Setup
Select recovery vehicle(s) with sufficient pulling capacity for the load and terrain conditions. Ensure the recovery platform is stable and capable of maintaining traction under load.
Secure Connection
Attach the strap only to rated recovery points. Ensure correct alignment to maintain a straight load path. In higher-resistance scenarios, dual connection methods may be used to improve load distribution.
Controlled Pull
Apply slow, progressive force to initiate movement. Maintain synchronised and consistent pull. Avoid all shock loading, sudden acceleration, or uneven force application.
Maintain Movement
Maintain steady tension until full recovery is achieved. Continuously monitor system behaviour and adjust input to preserve stability and control throughout the operation.
Customers also viewed
HEAVY RECOVERY SYSTEM GUIDANCE
Frequently Asked Questions
Professional Heavy Recovery Context
This system is designed for professional recovery of heavy agricultural and construction equipment under controlled field conditions.
Load & Terrain Considerations
Recovery performance depends on total system resistance, including ground conditions, gradient, and machine load.
Controlled Recovery Execution
All operations must be carried out using controlled, steady force application. Shock loading, sudden acceleration, or uneven tension can compromise recovery stability and system safety.
What type of operations is the 180K strap designed for?
Used for professional-grade recovery of heavy agricultural and construction equipment under controlled field conditions.
Is a single recovery vehicle normally sufficient?
Yes. The 180K system is typically designed for single-vehicle recovery operations in heavy-duty environments.
Can I use it for dynamic or kinetic recovery?
It provides higher load capacity and greater stability under resistance, making it suitable for heavier machinery and more demanding terrain conditions.
Can it be used for fully loaded dump trucks or haul vehicles?
Yes, in controlled static recovery scenarios depending on total resistance and ground conditions. Extreme gradient or fully loaded haul conditions may require higher-capacity systems.
Is shock loading acceptable at this level?
No. All recovery must remain controlled and gradual to maintain system integrity and operator safety.
When should a higher-capacity system be considered?
When total drawbar pull, terrain resistance, or vehicle mass exceeds the safe operating range of single-vehicle recovery systems.
